Countersunk Head Worm Gear Screws
Head Shape:Countersunk Head
Diameter:M3 M4 M5 M6
Grade：GR5
Titanium Content: 98%
Color: green, blue, gold, black, purple, rainbow, etc
Surface Treatment: Anodizing
Forming Process: CNC
Minimum Order Quantity: 200 PCS
Delivery Time: 7-20 Days
Features Of The Product
1. Compared to Countersunk head titanium alloy bolts produced of other materials, our high-quality titanium alloy bolts exhibit superior corrosion resistance since they are manufactured using a range of processing techniques.
2. The connecting part's smooth and elegant surface contrasts with the bolt's countersunk head shape.
3. The bolt strength of this titanium alloy is quite strong, reaching 880 MPa, with a yield strength of up to 820 MPa.
4. Good elongation performance, with up to 10% elongation.
5. Our titanium alloy fasteners exhibit exceptional environmental adaptability, making them appropriate for use in harsh environments such as seawater and salt spray.
Product Introduction
Product Introduction
|
Item |
Description |
|
Product name |
Countersunk titanium alloy bolts |
|
Product type |
bolts |
|
Material |
Titanium alloy GR5 |
|
Surface treatment |
Anodizing, polishing, passivation, etc |
|
Thread type |
Metric system, imperial system |
|
Head shape |
Countersunk head |
|
Length |
Standard length or customized according to customer needs |
|
Strength class |
The standard strength grade of the corresponding material |
|
Applicable environment |
Aviation, aerospace, petroleum, chemical, medical, electronics, Marine and other high-demand fields |
|
Executive standard |
GB, ISO, DIN, ANSI, ASME and other international standards and industry standards |
|
Features |
1. Light weight, high strength, excellent corrosion resistance 2. High temperature resistance, oxidation resistance, fatigue resistance is good 3. Suitable for strict environment, such as aerospace, medical equipment, etc |
Product Specifications
Please refer to the detailed specification sheet below to select the appropriate specifications.
Product Specification
|
Specification |
Diameter (mm) |
Length (mm) |
Cephalic diameter (mm) |
Head thickness (mm) |
Screw pitch (mm) |
Materials and handling |
|
M3×6 |
3 |
6 |
5.5 |
1.7 |
0.5 |
TC4 titanium alloy |
|
M3×8 |
3 |
8 |
5.5 |
1.7 |
0.5 |
TC4 titanium alloy |
|
M4×10 |
4 |
10 |
7 |
2.3 |
0.7 |
TC4 titanium alloy |
|
M4×12 |
4 |
12 |
7 |
2.3 |
0.7 |
TC4 titanium alloy |
|
M5×16 |
5 |
16 |
8.5 |
2.8 |
0.8 |
TC4 titanium alloy |
|
M5×20 |
5 |
20 |
8.5 |
2.8 |
0.8 |
TC4 titanium alloy |
|
M6×20 |
6 |
20 |
10 |
3.3 |
1 |
TC4 titanium alloy |
|
M6×25 |
6 |
25 |
10 |
3.3 |
1 |
TC4 titanium all |
Why choose us
Why Choose Us
Our Factory
With modernized production workshop and advanced CNC equipment, we focus on the processing and manufacturing of titanium, zirconium, nickel and other non-ferrous metal products
Our Products
We mainly produce titanium products such as titanium tubes, titanium plates, titanium rods, etc., which are widely used in aerospace, medical equipment, petrochemical, energy, electronic and electrical appliances and other fields.
Sales Market
Our products are exported to Europe, America, Asia and other places, and we have established long-term and stable cooperative relationships with international customers.
Service
We provide support for drawing processing, sample processing and foreign trade orders, covering the whole process of pre-sale, sale and after-sale services..
FAQ
Q1. How do we ensure excellence?
A:Prior to mass production, there is always a pre-production sample, and before shipment, there is always a final inspection.
Q2: What products do you offer?
A:Titanium alloy rods, plates, wires, springs, and special titanium alloy standard parts for modification.
Q3. How is it packaged?
A:Either exclusive customisation or neutral packaging.
Q4:Regarding product customization?
A:Our factory supports product customization. We can produce products according to the drawings provided by customers, using professional equipment and skilled machine operators, and we have the capability to complete product manufacturing according to customer requirements, ensuring both quality and quantity.
